Disc feeder

Disc feeder
Feeding size:
20-80 mm
Processing capacity:
Applicable materials:
Widely used in metallurgy, mining, building materials, coal, electric power and other industries of all kinds of viscous material feeding.
Product Description

The disc feeder is widely used in metallurgy, mining, building materials, coal, electric power and other industries of all kinds of viscous material feeding.

As a fine material feeding device, applicable to transport powdered, granular or small state of non viscous materials, such as coal, cement, clinker, limestone, shale, coal, clay and other powdered, granular material. Widely used in gold concentrator, mining with chemical plants, infrastructure and machinery foundry and other continuous and uniform, quantitative to material and ingredients.

Disc feeder

Features

1.Easy to install and maintain
2.Adjustment convenience
3.Superior quality, material is durable
4.Low factory price, good reputation in peer industry

Technical parameters
Model Disc Diameter (mm) Disc Rovelution (rpm) Max Feeding Size (mm) Feeding Capacity (tph) Motor Power (kw) Weight (kg)
YG300 300 10. 0 20 0 -1. 8 Y80L- 4 0. 55 115
YG400 400 10. 7 20 0 -2. 6 Y80L- 4 0. 55 120
YG500 500 10.7 20 0-3. 3 Y90L- 6 1. 1 124
YG600 600 10. 0 20 0 -5. 0 Y90L- 6 1.1 130
YG800 800 9 30 0 -8. 0 Y80L- 4 0.55 195
YG1000 1000 9 30 0-12 Y90L- 4 1. 5 263
YG1500 1500 7 40 0-22 Y132M2-6 5. 5 755
YG2000 2000 5 50 0-80 Y160L-6 11 2517
DK600 600 7. 53 25 1. 8-3. 9 Y90L- 6 1. 1 410
DK800 800 7. 53 30 3. 5 -7. 6 Y90L- 6 1.1 600
DK1000 1000 7. 50 40 1.8-16.7 Y100L- 6 1. 5 725
DK1300 1300 6. 5 50 4. 3 -27. 9 Y132S- 6 3 846
DK1600 1600 6 60 7.03 -48.6 Y132M1- 6 4 1980
DK1800 1800 5 70 9.26 -60 Y132M2- 6 5.5 3070
DK2000 2000 5 80 13.6 -88 Y132M2- 6 5.5 3260
