Speed governing constant weight feeder

Speed governing constant weight feeder
Feeding size:
Processing capacity:
Applicable materials:
Widely used in the industries of cement, electric power, metallurgy, chemical industry, food, feed, and other industries.
Product Description

The TDG Speed governing constant weight feeder is a new type of conveying, feeding, weighing and controlling device, which can be digested, absorbed and improved on the basis of advanced technology at home and abroad.It is suitable for weighing and quantitative feeding in the process of dynamic conveying of the block, the material solid material or the powder material,and is widely used in the industries of cement, electric power, metallurgy, chemical industry, food, feed, and other industries, as the automatic dynamic continuous measurement and control device of ingredients.

The product is controlled by the computer system, the most advanced Chinese weighing control instrument on the spot, and can also be matched with the variable frequency speed controller single way to measure and quantify the material feeding.

Speed governing constant weight feeder

Technical parameters

model

geared motor

model specification

(SBD65、75、85)

Belt speed


(m/s)

load cell


(kg)

Inverter rated speed


(Hz)

Station output


(t/h)

Reference station output


(t/h)
TDG650 SBD65-1923-1.5k 0.0082 100 50 0.1-10 0.2-0.8
TDG850 SBD65-619-1.5k 0.0254 100 50 0.4-4.0 0.65-3.2
TDG800 SBD65-253-2.2k 0.0621 100 50 2.0-20 4.0-16
TDG800 SBD65-150-1.5k 0.1539 100 50 4.0-40 10-32
TDG1000 SBD75-150-3k 0.1723 200 50 10-100 40-80
TDG1200 SBD75-150-3k 0.2661 200 50 16-160 80-100
TDG1400 SBD75-102-4k 0.3017 200 50 20-200 100-150
TDG1600 SBD85-102-5.5k 0.3565 200 50 35-350 150-300
TDG1800 SBD85-90-5.5k 0.4358 300 50 50-440 200-400
TDG2000 SBD85-90-7.5k 0.5603 300 50 100-600 300-600
